酒店廚房排煙罩采用不銹鋼拉絲工藝，不僅外觀美觀，而且防腐防銹。酒店廚房排煙罩內腔采用大空間設計，使油煙雜質吸收更充分，油煙吸收率應大于95%。那你知道濟南酒店廚房排煙罩的生產、安裝方法及日常維護事項是怎樣的嗎？

The smoke exhaust hood of the hotel kitchen adopts excellent stainless steel wire drawing process, which not only has beautiful appearance, but also has corrosion prevention and rust prevention. The interior of the smoke exhaust hood in the hotel kitchen is designed with large space to make the absorption of oil smoke impurities more sufficient, and the absorption rate of oil smoke should be greater than 95%. Do you know the production, installation and daily maintenance of kitchen smoke hoods in Jinan Hotel?

食堂油煙機排煙罩生產要求。

Production requirements for smoke exhaust hood of cooking fume hood in canteen.

1.油網煙罩后密封板、前密封板、前頁、上滑槽和下滑槽的所有外露邊緣均有扣邊；

1. All exposed edges of the rear sealing plate, front sealing plate, front page, upper chute and lower chute of the oil screen smoke hood have buckle edges;

2.油網煙罩后密封板與前密封板分段短焊，其中前密封板HL表面暴露；

2. The rear sealing plate and the front sealing plate of the oil screen hood are short-welded in sections, and the HL surface of the front sealing plate is exposed;

3.油網煙罩前頁與油網煙罩前封板連接為分段短焊，焊接面在前封板外露前頁HL面向下，二端煙罩連接面分別向上90度；

3. The connection between the front page of the oil screen smoke hood and the front sealing plate of the oil screen smoke hood is short welding in sections. The welding surface is facing downward on the exposed front page HL of the front sealing plate, and the connection surface of the two end smoke hoods is 90 degrees upward;

4.油網煙罩二端的油煙網罩側密封板和后密封板。前密封板的前頁分段短焊，包括同一前頁的前端（注：尺寸120mm）。后密封板的油槽位置為全焊和拋光；

4. The side sealing plate and rear sealing plate of the oil smoke screen cover at the two ends of the oil smoke screen cover. The front page of the front sealing plate is short-welded in sections, including the front end of the same front page (note: size 120mm). The oil groove of the rear sealing plate is fully welded and polished;

5.煙罩照明燈須具有防水功能，導線須具有旋轉穿線護管。

5. The smoke hood lamp must be waterproof, and the wire must have a rotating threading protection tube.

酒店廚房排煙罩的安裝方法。

Installation method of smoke exhaust hood in hotel kitchen.

1.現場安裝油煙網罩時，現場拼接的油網煙罩后密封板到油槽處滿焊，其余部分為短焊；

1. When installing the oil smoke screen cover on site, the rear sealing plate of the oil smoke screen cover spliced on site shall be fully welded to the oil tank, and the rest shall be short-welded;

2.用M8鋼膨脹螺和不銹鋼大墊片用于固定油煙網罩和墻壁，膨脹螺釘外露螺紋需螺紋；

2. M8 steel expansion screw and stainless steel large gasket are used to fix the oil smoke screen cover and wall, and the exposed thread of the expansion screw needs to be threaded;

3.油網煙罩前頁與地板連接件為螺釘全線或鋼絲繩加吊環螺釘，索具螺旋扣；

3. The connection between the front page of the oil screen smoke hood and the floor is the full line of screws or steel wire rope plus eyebolts and rigging turnbuckles;

4.吊裝高度:油網煙罩前頁下口距地面2000mm，油網煙罩后密封板至油槽底部距地面1900mm；油網煙罩的吊裝精度一般為正負10mm。

4. Hoisting height: the lower opening of the front page of the oil screen hood is 2000mm from the ground, and the rear sealing plate of the oil screen hood to the bottom of the oil tank is 1900mm from the ground; The lifting accuracy of oil screen smoke hood is generally plus or minus 10mm.

酒店廚房排煙罩維修方法。

Maintenance method of smoke exhaust hood in hotel kitchen.

1.平時不銹鋼櫥柜要避免熱鍋或熱水壺直接接觸櫥柜，這些物品較好放在鍋架上。

1. The stainless steel cabinet should avoid the hot pot or hot pot directly contacting the cabinet, and these items should be better placed on the pot rack.

2.平時注意尖銳物品不能觸摸臺面，避免廚房排煙罩造成櫥柜上有劃痕或凹痕。

2. Pay attention not to touch the table with sharp objects at ordinary times to avoid scratches or dents on the cabinet caused by the kitchen smoke hood.

3.柜門板根據不同的材料進行不同的清洗方法。

3. The cabinet door plate shall be cleaned according to different materials.

4.避免使用化學物質接觸櫥柜，對櫥柜造成損壞。

4. Avoid using chemicals to contact the cabinet and cause damage to the cabinet.

上述就是為您介紹的有關食堂/飯店油煙機排煙罩的制作要求、安裝方法及日常養護方法的內容，對此還有什么不了解的，歡迎前來咨詢我們的網站http://m.ajdlpj.cn，我們會有專門的技術人員為您講解。

The above is the content about the production requirements, installation methods and daily maintenance methods of the smoke exhaust hood of the kitchen ventilator in the canteen/hotel introduced to you. If you don't know anything about this, please come to our website http://m.ajdlpj.cn , we will have special technicians to explain to you.
