安裝風管時會遇到哪些常見問題呢?

來源：http://m.ajdlpj.cn 日期：2020-06-12 發布人：admin

風管主要是指空調系統的通風管道,它常常被忽視但它卻是空調系統的重要組成部分，那么，我們在安裝風管時會遇到哪些常見問題呢?如何解決呢?下面一起來看看吧。

The air duct mainly refers to the ventilation duct of the central air conditioning system, which is often ignored but it is an important part of the air conditioning system. Then, what common problems will we encounter when installing the air duct? How to solve them? Let's take a look.

風管安裝有哪些常見問題?

What are the common problems with duct installation?

1、材料不符合質量要求

1. Material does not meet quality requirements

這種問題是比較讓人頭疼的問題，如果材料不符合要求，系統運行時，風管會漏風，造成不應有的空調負荷損失，并且影響風管的使用壽命。

This kind of problem is quite a headache. If the material does not meet the requirements, the air duct will leak when the system is running, resulting in the loss of air conditioning load and affecting the service life of the air duct.

2、風管出現噪聲

2. Duct noise

引起這種現象的原因可能是板材表面不平整，厚度不均勻，有明顯的壓痕、裂紋、砂眼、結疤和銹蝕等，或者是風管平面下沉，側面向外凸起，有明顯的變形。

The cause of this phenomenon may be the uneven surface and thickness of the plate, obvious indentation, crack, sand hole, scar and rust, etc., or the air duct plane sinks, the side bulges outwards, and obvious deformation.

3、風管翹角、扭曲及彎頭角度不準

3. The angle of air duct warping, twisting and the angle of elbow are not correct

這是由于板下料放樣不準確;風管兩兩平行，相對面的板料長度和寬度不相等;風管的四角處咬口寬度不相等;咬口縫設置部位不對，手工咬口縫用力大小不一樣;未采取相應的加固措施。這樣的情況會導致矩形風管相對平面不平行、兩端面不平行;折角不平直;對角線不相等;咬口不嚴。的直接結果就是會使風管連接受力不均勻，安裝后的風管不平直，法蘭盤墊片不嚴密，系統漏風，造成空調負荷損失，并且縮短使用壽命。

This is due to the inaccurate setting out of slab cutting; the two air ducts are parallel, and the length and width of the slab on the opposite side are not equal; the width of the undercut at the four corners of the air duct is not equal; the location of the undercut joint is not correct, and the strength of the manual undercut joint is not the same; no corresponding reinforcement measures have been taken. In this case, the relative plane of the rectangular air duct is not parallel, and the two ends are not parallel; the angle is not straight; the diagonal is not equal; and the undercut is not strict. The final direct result is that the air duct connection will be uneven in stress, the installed air duct is not straight, the flange gasket is not tight, the system leaks air, resulting in air conditioning load loss, and shortening the service life.

風管安裝的解決辦法：

Solutions for duct installation:

1、安裝前對材料進行質量檢查

1. Quality inspection of materials before installation

仔細測量鋼板厚度，在風管安裝前一定要注意先檢查材料出廠合格證書和材料質量證明，然后檢查材料外觀;再測量鋼板厚度。防止因材料不符合要求而返工。

Carefully measure the thickness of the steel plate. Before installing the air duct, be sure to check the factory certificate and material quality certificate of the materials, then check the appearance of the materials, and then measure the thickness of the steel plate. Prevent rework due to non-conforming materials.

2、吊裝安全要保證

2. Safety of hoisting

潔凈風管的吊裝與普通風管一樣，要求吊桿、橫擔、膨脹螺栓、保溫風管下部墊木等符合有關規范和質量驗收標準。

The hoisting of clean air duct is the same as that of ordinary air duct, and the suspender, cross arm, expansion bolt, underlay of thermal insulation air duct, etc. are required to meet the relevant specifications and quality acceptance standards.

3、注意展開下料步驟

3. Pay attention to unfolding the blanking steps

要讓施工人員對板料嚴格檢查，對每片板料的長度、寬度以及對角線，使它們的偏差控制在允許范圍內;下料后的板料，應該將風管相對面的兩片板料重合起來，檢驗尺寸的準確性;板料咬口預留尺寸必須正確，以保證咬口寬度一致;咬口縫設在四角部位，手工咬口合縫時，用木錘先將咬口兩端部位打緊，再沿全長均勻打?qū)崱?/div>

The construction personnel shall strictly check the sheet metal, and control the length, width and diagonal of each sheet metal to make their deviation within the allowable range; for the sheet metal after blanking, the two sheets on the opposite side of the air duct shall be overlapped to check the accuracy of the size; the pre reserved size of the sheet metal undercut must be correct to ensure the same undercut width; The seaming joint is set at the four corners. When the seaming joint is made by hand, the center part at both ends of the seaming joint shall be tightened with a wooden hammer first, and then the joint shall be evenly compacted along the whole length.

4、做好漏光檢查

4. Check the light leakage

風管地面組裝后，在未做保溫前應進行漏光檢查，根據現場情況可按內漏光或外漏光檢查，在漏光處需補密封膠，直至無漏光時方可進行保溫。

After the air duct is assembled on the ground, the light leakage inspection shall be carried out before the heat preservation. According to the site conditions, the light leakage inspection can be carried out according to the internal light leakage or external light leakage. Sealant shall be added at the light leakage place until there is no light leakage.

5、漏風量測試

5. Air leakage test

對于等級較高的凈化系統的送回風總管和支干管，在地面組對后除做漏光檢查外，還應做漏風量測試。對于較小的系統可在風管安裝后測試，對于較大的系統盡可能在地面分段組裝后進行，這樣便于發現問題及時處理。

For the air supply and return main pipe and branch main pipe of the purification system with higher level, besides light leakage inspection, air leakage test shall also be conducted after the ground assembly. For the smaller system, it can be tested after the installation of air duct, and for the larger system, it can be assembled in sections on the ground as much as possible, so that problems can be found and dealt with in time.

6、墊料要選好

6. Select the padding

風管法蘭連接處的墊料，應選擇不透氣、不產塵、彈性好不易老化的材料，如閉孔海綿橡膠板、軟橡膠板等組成，墊料的厚度5～8mm，接頭處應加工成階梯形，嚴禁直接對接。

The gasket at the joint of air duct flange shall be made of airtight, dust-free, elastic and aging resistant materials, such as closed cell sponge rubber plate, soft rubber plate, etc. the thickness of the gasket shall be 5-8mm, and the joint shall be processed into ladder shape, and direct butt joint is strictly prohibited.

關于風管安裝的相關知識小編就給大家介紹到這里，風管安裝是否規范非常重要，大家在施工過程中要仔細。

The relevant knowledge of air duct installation will be introduced here. Whether the air duct installation is standard or not is very important. You should be careful in the construction process.
